Pneumatic Conveying Silo 12" Rotary Harge Valve For Pulverized Coal
Product Introduction of Rotary Discharge Valve
Rotary feeders are mainly used at the initial feeding in the negative and positive pressure conveying systems with a pressure difference of not more than 1 bar (Kg/cm2). Design features: housing and main parts are made of precision casting, and the appearance is beautiful; the entrance is circular and connected with the silo or pipeline, which is compact in structure, saving space and easy to install;
Characteristics: 1.Strong structure,convenient intallation. 2.Stable operation,low noise. 3.Two sets sliding bearings and deep groove ball bearings for better seals and longer working life.
Where to use: it will be used as the below picture shows, dosing, batching, silo emptying, mixing, screw feeder feeding, machiniery and equipment feeding, gravity conveying conveying, etc.
Cheegers Rotary Valve Model Interpretation
| Chegers Machinery RV Series Rotary Valve Model Interpretation |
| Model Format:Product Model.Classification Model--Equipment Volume Like RV-D.P-12L |
| Note: If there is a parallel classification relationship, it should be arranged in the order of feeding form, pressure, wear resistance, micro feeding and cleaning type, and the English stop ".Interval for example: tangential normal pressure wear resistant fast cleaning 12L drop-through rotary valve——RV-D.T.N.AR.SC-12L |
| Product Model | English Interpretation |
| RV-B | Rotary Valve-Blow Through |
| RV-D | Rotary Valve-Drop Through |
| Classification Model | |
| T | Tangential |
| SC2 | Self-Cleaning 2代 |
| SC1 | Self-Cleaning 1代 |
| N | Normal Discharge |
| P | Positive Pressure |
| V | Vacuum |
| QC | Quick-Cleaning |
| M | Micro |
| PI | Pulse Inject |
| AR | Abrasion-Resistant |
| HP | High Pressure |
| HT | High Temperature |
| Note: Flange standard, material requirements, accessories, transmission form, power configuration and so on are explained in the product remarks. |
Dimension Display of Star Dust Discharge Valve
| Type | Inlet outlet | Size |
| C | D | H | h | A | B | E | F | Φ | Power |
| TGFZ-5L | 150 | 150 | 400 | 200 | 250 | 250 | 105 | 105 | 250 | 1.1kw |
| TGFZ-7L | 200 | 200 | 440 | 220 | 300 | 300 | 130 | 130 | 250 | 1.1kw |
| TGFZ-9L | 250 | 250 | 440 | 220 | 350 | 350 | 155 | 155 | 250 | 1.1kw |
| TGFZ-12L | 300 | 300 | 440 | 220 | 400 | 400 | 180 | 180 | 250 | 1.5kw |
| TGFZ-20L | 300 | 300 | 460 | 230 | 400 | 400 | 180 | 180 | 300 | 1.5kw |
| TGFZ-30L | 350 | 350 | 520 | 260 | 450 | 450 | 204 | 204 | 350 | 2.2kw |
Overseas Exhibitions
Cheegers has been engaged in exhibitions home and abroad for some time, like Thailand, Turkey, Iran, Pakistan, etc.
We supply rotary valves for many brands in China, like Buhler, Sataka, Cofco, Yihai Kerry, Muyang, etc.
Compamy Profile
Chengdu Cheegers Machinery Limited Company is committed to researching and manufacturing rotary valve, diverter valve, slide gate valve and magnet separator used in bulk solids conveying over half a century, having accumulated rich experience in design and producing. Cheegers gains a good reputation in maket home and abroad. In China, we have cooperation with Buhler, Cofco, Sinograin, Yihai Kerry, Sataka and so on. Overseas, our valves are exported to more than, 30 countries, like Thailand, Korea, Malaysia, Phillipine, Australia, Singapore, America, the Uk, Canada, Dubai, Saudi Arabia, etc.
Factory Overview
For every production step our workers are carefully finished. QC department is strictly following the quality standard by 100% inspection for all the products. Cheegers never stop studying,researching and developing new designs on rotary valves. Each year, we will launch new designs which suit different application conditions.
Packaging & Delivery
Apart from the standard rotary valves we have in stock, our rotary valves generally need 40-45 days to finish.
We will use plywood case to pack, which can avoid the fumigation.
Certificate
Cheegers has got the CE for Rotary discharge valve and diverter valve as below:
We also have other patents for rotary valve and diverter valve domestically.
Like high airtight rotary airlock valve patent, apprearance patent for airlock valves, etc
